Product Details:

Simple Operation

High Accuracy

Non-contact Measurement

One-click measurement of multiple data

Comes with a case management system and built-in database, capable of saving over 10,000 customer test records

Can simultaneously complete measurements of axial length, refractive power, and curvature

Main Technical Parameters:

The measurement range for spherical lens power is -30D to +25D (minimum resolution of 1D)

The measurement range for cylindrical lens power is 0 to 12D (minimum resolution of 1D)

The measurement range for radius of curvature is 6.5 to 10.5mm (minimum resolution of 0.01mm)

The measurement range for principal meridian axis position is 0 to 180° (minimum resolution of 1°)

The measurement range for axial length is 10 to 35mm (minimum resolution of 0.01mm)

The measurement range for white to white distance is 6 to 14mm (minimum resolution of 0.01mm)

The measurement range for interpupillary distance is 10 to 85mm (minimum resolution of 1mm)

The measurement range for pupil diameter is 1 to 14mm (minimum resolution of 0.01mm)

Other Performance Parameters:

Uses a 10.1 inch capacitive screen (adjustable viewing angle)

Printer: 57mm thermal printer
